NuTone GSEH3K User Manual

HEPA FILTRATION UNIT AND FRESH AIR VENTILATION,
MODEL GSVH1K
HEPA FILTRATION, FRESH AIR AND HEAT RECOVERY
VENTILATION, MODEL GSHH3K
HEPA FILTRATION, FRESH AIR AND ENERGY RECOVERY
VENTILATION, MODEL GSEH3K
FRONT VIEW TOP VIEW
2. TECHNICAL DATA (CONT’D)
- 5 -
2.1 DIMENSIONS AND AIR DISTRIBUTION PORTS
HEPA FILTRATION UNIT, MODEL GSFH1K
FRONT VIEW TOP VIEW
17.8''
(452 mm
29''
(737 mm)
22.9'' (581 mm)
VK0047
29.4''
(748 mm)
VK0048A
17.8''
(452 mm)
22.9'' (581 mm)
VF0029
STALE AIR
FROM
BUILDING
STALE AIR
TO
OUTSIDE
FRESH
AIR FROM
OUTSIDE
FRESH AND FILTERED
AIR TO BUILDING
VF0033
STALE AIR
FROM
BUILDING
FILTERED AIR
TO BUILDING
FRONT
FRONT
2.2 VENTILATION PERFORMANCES
2.2.1 GSVH1K VENTILATION PERFORMANCES
NOTE: all tests performed at high speed.
EXT. STATIC NET VENTILATION GROSS AIR FLOW
POWER
PRESSURE AIRFLOW SUPPLY EXHAUST FILTERED
Pa
50
100
in.w.g.
0.2
0.4
L/s
52
49
cfm
110
104
L/s
56
52
cfm
118
111
L/s
54
49
cfm
115
104
L/s
132
121
cfm
279
257
Watts
231
224
