NuTone GSEH3K User Manual

- 6 -
2. TECHNICAL DATA (CONT’D)
2.3 MOUNTING AND SERVICING CONSIDERATIONS
• The two following pictures are showing the minimum clearance needed to open the door completely.
22.5” 15.75”
(572 mm) (400 mm)
VD0117
VD0116
22”
(559 mm)
NOTES: 1. The unit door is removable. To do so, remove the stopper (A) located on the right side
of the door hinge, then, slide the door out of its hinge. For servicing, a minimum of 15’’
(381 mm) clearance from any obstruction in front of the unit is sufficient to open the door
and remove it.
2. A minimum of 8” (203 mm) clearance from any obstruction on top of the unit is required
for the ductwork radius turn.
8”
(203 mm)
VD0118A
8¾”
222 mm
9¾”
248 mm
• The joist opening needed to install the Tandem
®
transition must be 9¾” (248 mm)
minimum. Also, the maximum height of the Tandem
®
transition is 8¾” (222 mm).
See Tandem
®
transition end view beside.
NOTES: 1. If there is not enough space to use the Tandem
®
transition, the optional exterior
single hood must be installed to bring the fresh outside air to the unit.
See Section 6.8.
2. When installing a HEPA Filtration model GSFH1K, there is no Tandem
®
transition.
2.2 VENTILATION PERFORMANCES (CONT’D)
2.2.2 GSHH3K V
ENTILATION PERFORMANCES 2.2.3 GSEH3K VENTILATION PERFORMANCES
NOTE: all tests performed at high speed.
EXT. STATIC NET VENTILATION GROSS AIR FLOW
POWER
PRESSURE AIRFLOW SUPPLY EXHAUST FILTERED
Pa
50
100
in.w.g.
0.2
0.4
L/s
52
49
cfm
110
103
L/s
58
55
cfm
124
116
L/s
57
51
cfm
121
108
L/s
131
119
cfm
277
252
Watts
237
229
EXT. STATIC NET VENTILATION GROSS AIR FLOW
POWER
PRESSURE AIRFLOW SUPPLY EXHAUST FILTERED
Pa
50
100
in.w.g.
0.2
0.4
L/s
57
53
cfm
122
113
L/s
50
48
cfm
105
102
L/s
59
55
cfm
125
117
L/s
127
120
cfm
270
254
Watts
227
224
VD0170
A
