SN3700/SN3700C Telescopic Rail Kit
There are two installation kit options:
Standard depth systems should be mounted using the standard rail kit.
Short depth systems can be mounted using either of the rail kits.
Kit Part Number Legacy Kit Part Number Rack Size and Rack Depth Range
930-9BRKT-00JJ-000 MTEF-KIT-F 600-800 mm
The following parts are included in the rail kit package (see gure below):
1x Right side slider (A)
1x Left side slider (B)
2x Rear rail (C)
2x Front rail (D)
10x M6 Standard cage nuts¹ ² (E)
10x M6 Standard pan-head Phillips screws¹ (F)
2x Phillips100 DEG F.H TYPE-I ST.ST 6-32 X 1/4 screw with around patch (G)
6x Flat head 100 DEG Phillips 4-40X3/16" ST.ST patch screws (H)
¹ Other threads are available by special order: M5, 10-32, 12-24
² G-type cage-nut is available by special order.
Note
The telescopic rail kit is not included in the system’s package, and can
be purchased separately.
