Nvidia Spectrum-2 SN3420 - System Bring-Up

NVIDIA Spectrum-2 SN3000 1U and 2U Switch Systems Hardware User Manual 108
System Bring-Up
For bring-up of a switch system with NVIDIA Onyx (MLNX-OS) operating system installed,
see Conguring Network Attributes Using NVIDIA Onyx (MLNX-OS).
For bring-up of a switch system with Cumulus Linux operating system installed, see
Conguring Network Attributes Using Cumulus Linux.
Conguring Network Attributes Using NVIDIA Onyx
(MLNX-OS)
The procedures described in this chapter assume that you have already installed and
powered on the system according to the instructions in this document. The system
comes with a pre-congured DHCP. If you wish to disable it, refer to Disable Dynamic Host
Conguration Protocol (DHCP). In case a manual conguration is required, please refer to
the instructions in Manual Host Conguration.
Manual Host Conguration
To perform initial conguration of the system:
Step 1. Connect a host PC to the Console RJ45 port of the system, using the supplied
harness cable (DB9 to RJ45).
spannungsfrei zu machen sind die Netzstecker aller Netzteile zu
entfernen.
ATTENTION Risque de choc et de danger e’lectriques. Le
de’branchment d’une seule alimentation stabilise’e ne de’branch
uniquement qu’un module “Alimentation Stabilise’e”. Pour isoler
completement le module en cause, Il faut de’brancher toutes les
alimentations stabilise’es.
Note
Make sure to connect to the Console RJ45 port, and not to the
(Ethernet) MGT port. Pay attention to the icons:
