NXP Semiconductors MPC5748G User Manual

 4 user LED’s wired to MCU ports. 

 2 user pushbutton switches wired to MCU ports. 
 Hexadecimal encoded switch wired to 4 MCU ports. 
 Simple potentiometer connected to analogue input channel. 
2.1.
Differences to the Customer EVB
Note that the GPIO pins used for peripherals on the LCEVB are the same as those used on the
customer EVB. This ensures maximum code compatibility between the 2 boards, making it easy to
migrate from one board to the other
Table 1. Customer EVB vs LCEVB features
Feature
Customer EVB
LCEVB
MCU Support
Custom MCU Daughter cards for
Soldered 176QFP MPC5748G
multiple devices (socketed)
Power Supply
External 12 V
External 5 V (Caution)
On Board Regulators (and LED’s)
5
V, 3.3 V, 1.25 V (combination of
3.3 V Switching Regulator
Linear and /or Switching regulators)
Master Power Switch
Yes
Yes
Reset Control
Reset button with MCU and External
Reset button with MCU and External
Reset LED’s
Reset LED’s
USB FTDI Serial Interface
Yes
Yes
CAN Physical Interfaces
2
(routed to 0.1” headers)
2
(routed to 0.1” headers)
LIN Physical Interfaces
2
(routed to Molex headers)
2
(routed to 0.1” headers)
FlexRay Physical Interfaces
2
(routed to 0.1” headers)
2
(routed to 0.1” headers)
Ethernet Physical Interface
1
(MII and RMII Support)
1
(MII only mode)
USB Physical Interface
2
(USB Host and OTG)
1
(USB Host)
MLB Daughter card Connector
Yes
No
SAI Audio / TWRPI Connectors
Yes
No
SDHC Connector
Full Size SDHC Socket
No
Fast External Osc (FXOSC)
Daughter card Crystal * and
40 MHz Crystal
SMA input connector
Slow External Osc (SXOSC)
Daughter card Crystal *
32.768 KHz Crystal
CLKOUT signals available
Yes (GPIO Matrix)
Yes (Standalone pads)
User LEDS
4
4
User Pushbutton Switches
4
2
Hex Encoded Switch
Yes
Yes
Test Potentiometer for ADC
Yes
Yes
GPIO Matrix
All Available Pins not otherwise used
Selection of Pins available from 5
for peripherals
GPIO Ports
Debug
14 Pin JTAG and 50 pin Nexus
14 Pin JTAG
Configuration
Highly configurable via jumper shunts
Fixed (limited configuration via 0 ohm
resistors)
* Daughter card crystals are typically 40 MHz for FXOSC and 32.768 KHz for SXOSC but may
vary between daughter cards.
MPC5748G Low Cost EVB User Guide, Rev. 1, 08/2016
4 NXP Semiconductors
