4.1.1.2 Supported RF standards
Table 6. AW-CM358MA supported RF standards
Part number Wi-Fi Bluetooth
AW-CM358MA 1x1 Wi-Fi 5 (2.4/5GHz) 5.0
4.1.1.3 Wi-Fi features
Table 7. AW-CM358MA supported Wi-Fi features
Feature Description
Wi-Fi standard IEEE802.11 a/b/g/n/ac
Frequency range 2.4 GHz ISM Bands 2.412-2.472 GHz
5.15-5.25 GHz (FCC UNII-low band) for US/Canada and Europe
5.25-5.35 GHz (FCC UNII-middle band) for US/Canada and Europe
5.47-5.725 GHz for Europe
5.725-5.825 GHz (FCC UNII-high band) for US/Canada
Modulation 802.11a/g/n/ac: OFDM
802.11b: CCK(11, 5.5Mbps), DQPSK(2Mbps), BPSK(1Mbps)
Number of channels 802.11b:
USA, Canada and Taiwan – 1 ~ 11
Most European Countries – 1 ~ 13
802.11g:
USA and Canada – 1 ~ 11
Most European Countries – 1 ~ 13
802.11n:
USA and Canada – 1 ~ 11
Most European Countries – 1 ~ 13
802.11a:
USA – 36, 40, 44, 48, 52, 56, 60, 64, 100, 104, 108, 112, 116, 120, 124, 128, 132, 136,
140, 149, 153, 157, 161, 165
Data rate WLAN:
802.11b : 1, 2, 5.5, 11Mbps
802.11a/g : 6, 9, 12, 18, 24, 36, 48, 54Mbps
802.11ac/n : Maximum data rates up to 86.7 Mbps(20MHz
channel),200 Mbps (40 MHz channel), 433 Mbps (80 MHz channel)
Security WPA/WPA2 and WEP 64-bit and 128-bit encryption
WPA3 SAE encryption supported
Advanced Encryption Standard (AES)/Counter Mode CBC-MAC
Protocol (CCMP)
Wired Equivalent Privacy (WEP) /Temporal Key Integrity Protocol (TKIP)
Advanced Encryption Standard (AES)/Cipher-Based Message Authentication Code
(CMAC)
WLAN Authentication and Privacy Infrastructure (WAPI)
QoS 802.11e Quality of Service supported for multimedia applications
