8: Firmware and Advanced Communications
90 225-00000-000-11-201604
Command Syntax:
v
Response:
ACK followed by {DATA WORD}
Default value
N/A
Calibration Constants
Writes one of the 16 possible calibration constant to EEPROM. The calibration constant is
specified by the first DATA WORD which follows the x. The calibration constant is stored as an
ASCII string with a max length of 15 characters. The string does not check to see if it makes
sense.
Command Syntax:
x{DATA WORD}{ASCII STRING}
Value:
DATA WORD Index description
0 – Serial Number
1 – 0
th
order Wavelength Calibration Coefficient
2 – 1
st
order Wavelength Calibration Coefficient
3 – 2
nd
order Wavelength Calibration Coefficient
4 – 3
rd
order Wavelength Calibration Coefficient
5 – Stray light constant
6 – 0
th
order non-linearity correction coefficient
7 – 1
st
order non-linearity correction coefficient
8 – 2
nd
order non-linearity correction coefficient
9 – 3
rd
order non-linearity correction coefficient
10 – 4
th
order non-linearity correction coefficient
11 – 5
th
order non-linearity correction coefficient
12 – 6
th
order non-linearity correction coefficient
13 – 7
th
order non-linearity correction coefficient
14 – Polynomial order of non-linearity calibration
15 – Optical bench configuration: gg fff sss
gg – Grating #, fff – filter wavelength, sss – slit size
16 – Flame configuration: AWL V
A – Array coating Mfg, W – Array wavelength (VIS, UV, OFLV), L – L2 lens
installed, V – CPLD Version
17 – Reserved
18 – Reserved
19 – Reserved
Response:
ACK or NAK
