Chapter 6
Technical Specifications
Specification
FLAME-S
FLAME-T
Optical and Spectroscopic
Integration Time
10 µs – 65 seconds
3.8 ms to 10 seconds
Dynamic Range for single
acquisition
1
1300:1
Dynamic Range of
system
2
2 x 10
8
3.4 x 10
6
Signal-to-Noise (single
acquisition)
250:1
300:1
Resolution (FWHM)
0.1 – 10.0 nm (configuration dependent)
Scan rate (max)
3
400 Hz
260 Hz
Spectrometer Channels
One
Thermal Stability
0.02 nm/°C for 650 nm range, 0.06 pixels/°C
Triggering
4 modes
Triggering Jitter
21 nanoseconds
Detector
Type
Sony ILX511B CCD
Toshiba TCD1304AP CCD
Detector range
190–1100 nm
Pixels
2048 pixels
3648 pixels
Pixel size
14 µm x 200 µm
8 µm x 200 µm
Electronic shutter
No
Yes
Pixel well depth
~62,500 electrons
~100,000 electrons
Readout noise (single
dark spectrum)
50 counts RMS, 300 counts peak-to-peak
