Ocean Optics Flame-S - PAK50 Connector Cable (FLAME-CBL-DD4 P-PAK50 P); Breakout Box (HR4-BREAKOUT); Interchangeable Slits

2: Installation and Setup
16 225-00000-000-11-201604
PAK50 Connector Cable (FLAME-CBL-DD4P-PAK50P)
This cable connects the Flame to the Breakout Box.
DD4P to PAK50P 30-Pin Connections
PAK50P
DD4
Name
PAK50P
DD4
Name
1
25
RS232 Rx
16
11
GPIO 4
2
24
RS232 Tx
17
4
Single Strobe
3
8
GPIO 2
18
12
GPIO 5
4
40
VUSB
19
16
SPI CLK
5
1
GND
20
3
Continuous Strobe
6
21
I2C SCL
21
18
SPI CS
7
6
GPIO 0
22
13
GPIO 6
8
22
I2C SDA
23
28
Reserved (do not connect)
9
7
GPIO 1
24
NC
Reserved (NC)
10
2
External Trigger In
25
5
Lamp Enable
11
9
GPIO 3
26
14
GPIO 7
12
40
VUSB
27
10
GND
13
17
SPI MOSI
28
NC
Reserved (NC)
14
40
VUSB
29
15
GND
15
19
SPI MISO
30
NC
Reserved (NC)
For the DD4, connect shield to connector case, if shield is included.
Breakout Box (HR4-BREAKOUT)
The Breakout Box is a passive module that separates the signals from the Flame’s DD4 40-pin
connector to an array of standard connectors and headers, enabling functionality with a wide
range of accessories. In addition to the accessory connector, the breakout box features a circuit
board based on a neutral breadboard pattern that allows custom circuitry to be prototyped on
the board itself. See Product-Related Documentation to access the manual for the Breakout
Box.
Interchangeable Slits
The Flame offers the capability of changing the slit size to match your measurement needs. You
can order additional replacement slits either individually or as a kit (in various widths from 5 µm
to 200 µm). See Change the Slit and Chapter 5: How the Flame Spectrometer Works for more
information.
