8: Firmware and Advanced Communications
225-00000-000-11-201604 97
Packet #
End Point
# Bytes
Pixels
0
EP2In
64
0-31
1
EP2In
64
32-63
2
EP2In
64
64-95
…
EP2In
64
119
EP2In
64
3808–3839
120
EP2In
1
Sync Packet
Packet 0
Byte 0
Byte 1
Byte 2
Byte 3
Pixel 0 LSB
Pixel 0 MSB
Pixel 1 LSB
Pixel 2 MSB
…
Byte 62
Byte 63
Pixel 31 LSB
Pixel 31 MSB
Packet 120 – Synchronization Packet (1 byte)
Byte 0
0x69
Set Trigger Mode
Sets the Flame Trigger mode to one of the following states. If an unacceptable value is passed,
then the trigger state is unchanged.
Data Value = 0  Normal (Free running) Mode
Data Value = 1  Software Trigger Mode
Data Value = 2  External Synchronization Trigger Mode
Data Value = 3  External Hardware Trigger Mode
Byte Format
Byte 0
Byte 1
Byte 2
0x0A
Data Value LSB
Data Value MSB
Query Number of Plug-in Accessories
Queries the number of Plug-in accessories preset. This is determined at power up and
whenever the Plug-in Detect command is issued.
