5: How the Flame Spectrometer Works
225-00000-000-11-201604 43
Available Order-Sorting and Detector Window Options
Detector
Description
Spectrometer
DET2B-200-535
Sony ILX511B detector, installed, with Custom OFLV Coated
Window Assembly for Grating#5 and Grating#5U, S-bench
FLAME-S
DET2B-200-850
Sony ILX511 detector, installed, with 200 – 850 nm variable
longpass filter and UV2 quartz window; best for UV-VIS
systems configured with Grating #1 or #2
FLAME-S
DET2B-200-1100
Sony ILX511 detector, installed, with 200 – 850 nm variable
longpass filter and UV2 quartz window; best for UV-VIS
systems configured with XR-1 grating
FLAME-S
DET2B-350-1000
Sony ILX511 detector, installed, with 350 – 1000 nm variable
longpass filter; best for VIS systems configured with Grating
#2 or #3
FLAME-S
DET2B-UV
Sony ILX511 detector, installed, with UV2
quartz window; best for systems configured for <360nm
FLAME-S
DET2B-VIS
Sony ILX511 detector, installed, with VIS BK7 window; best
for systems configured for >400nm
FLAME-S
DET4-200-535
Toshiba TCD1304AP detector, installed, with Custom OFLV
Coated Window Assembly for Grating#5 and Grating#5U, S-
bench
FLAME-T
DET4-200-850
Toshiba TCD1304AP detector, installed, with 200 – 850 nm
variable longpass filter and UV2 quartz window; best for
systems configured with Grating #1 or #2
FLAME-T
DET4-200-1100
Toshiba TCD1304AP detector, installed, with 200 – 850 nm
variable longpass filter and UV4 quartz window: best for
systems configured with XR-1 grating
FLAME-T
DET4-350-1000
Toshiba TCD1304AP detector, installed, with 350 – 1000 nm
variable longpass filter; best for VIS systems configured with
Grating #2 or #3
FLAME-T
DET4-UV
Toshiba TCD1304AP detector, installed, with UV4 quartz
window; best for systems configured for <360 nm
FLAME-T
DET4-VIS
Toshiba TCD1304AP detector, installed, with VIS BK7 quartz
window: best for systems configured for >400 nm
FLAME-T
