Chapter 2
Installing the NIR Spectrometer
Overview
You must install the OOIBase32 software application prior to connecting the NIR Spectrometer to the
PC. The OOIBase32 software installation installs the drivers required for NIR Spectrometer installation.
If you do not install OOIBase32 first, the system will not properly recognize the NIR Spectrometer.
If you have already connected the NIR Spectrometer to the PC prior to installing OOIBase32, consult
Chapter 3:
Troubleshooting for information on correcting a corrupt NIR Spectrometer installation.
NIR Spectrometer Installation
This section contains instructions for connecting the NIR Spectrometer via both USB and serial modes.
USB Mode
Follow the steps in this section to interface the NIR Spectrometer via the USB port to a desktop or
notebook PC.
To connect the NIR Spectrometer to a PC via the USB port, the PC must be running the Windows
98/ME/2000/XP operating system.
►
Procedure
1. Install OOIBase32 on the destination PC, and then reboot the system.
2. Plug the +5VDC wall adapter (USB-CBL-PS) into an electrical outlet, then connect the
power cord to the 2.5 mm power jack (older versions may have a 1.3 mm power jack) on
the rear of the NIR Spectrometer.
3. Locate the USB cable (USB-CBL-1) that came with the NIR Spectrometer.
4. Insert the square end of the cable into the rear of the NIR Spectrometer, and then insert
the rectangular end into the USB port of the PC.
197-00000-512-02-0305 5
