B: Specifications
NIR512 NIR256-2.1 NIR256-2.5
Optical
resolution
~3.0 - 4.0 nm FWHM ~12.0 nm FWHM
Focal length f/4, 40mm
Dynamic range 5000:1 for a single scan
Fiber optic
connector
SMA 905 to single-strand optical fiber (0.22 NA)
A/D converter: 16-bit internal - 500 KHz
Data transfer
rate
Full scans into memory every 10 milliseconds (USB interface)
Integration time ≥1 msec
Fiber optic
connector
SMA 905 to single-strand optical fiber (0.22 NA)
Operating
systems
Windows 98/Me/2000/XP - USB interface
Any 32-bit Windows operating system – Serial port
Spectral Response Curves
42 197-00000-512-02-0305
