40
NOTE: The procedures that follow must be closely
adhered to. Damage due to improper battery replace-
ment is not covered by the VERSA's 2 year warranty.
Battery Hatch Removal
• Inspect the Button, Lens, and Housing to ensure they are
not cracked or damaged.
• If there is any sign of moisture in the module, DO NOT
use the Versa until it receives proper service by an Autho-
rized Oceanic Dealer, or the Oceanic factory.
• Locate the Battery Compartment on the back of the Hous-
ing.
• While applying steady inward pressure on the Battery
Hatch, rotate the Hatch Ring clockwise 10 degrees by
pressing on the upper/right arm of the Ring with a small
blade screwdriver (Fig. 43).
NOTE: If available, an adjustable face spanner tool or
a pair of pointed pliers can be used instead of the
screwdriver by inserting the tips of the tool in the
small holes in the Ring (Fig. 44).
• Lift the Hatch Ring up and away from the Housing.
• Remove the clear Battery Hatch.
Fig. 43 -Ring Removal
Fig. 44 -Ring Removal (alternate)
