42
Battery Installation
• Slide a new 3 volt type CR2450 Lithium Battery, negative
(-) side down into the Battery Cavity. Slide it in from the
right side and ensure that it slides under the contact clip
on the left rim of the cavity.
• Orient the Retaining Bar across the lower portion of the
Battery and carefully push it down into position (Fig. 46).
Battery Hatch and Hatch Ring Installation
• Replace the Hatch O-ring with new. This O-ring must be
a genuine Oceanic part that can be purchased from an
Authorized Oceanic Dealer. Use of any other O-ring
will void the warranty.
• Lightly lubricate the new Hatch O-ring with silicone
grease and place it on the inner rim of the Battery Hatch.
Ensure that it is evenly seated.
• Slide the Hatch Ring, top portion first (small opening),
onto your thumb (Fig. 47).
• Carefully place the clear Battery Hatch (with O-ring) into
position on the rim of the Battery Compartment, then
press it evenly and completely down into place with your
same thumb.
• Maintain the Battery Hatch securely in place and, using
your other hand, slide the Hatch Ring down off your
thumb and into position around the Battery Compartment.
Fig. 46 - Battery Installation
Fig. 47 -Hatch Installation
