43
VERSA
• The tabs on the Ring fit down into the slots located at the
2 and 9 o'clock positions (Fig. 48).
• Using your fingers, turn the Ring counter clockwise 5 de-
grees until the tabs engage, then tighten it 5 more de-
grees by turning it counter clockwise with the aide of a
small blade screwdriver, pressing against the upper/left
arm of the Ring (Fig. 49).
NOTE: If available, an adjustable face spanner tool
or pair of pointed pliers can be used by placing the
tips in the small holes of the Ring (Fig. 50).
Inspection
• Activate the Versa and watch carefully as it performs a
full diagnostic and battery check, and enters Surface
Mode. Observe the LCD display to ensure it is consis-
tently clear and sharp in contrast throughout the screen.
WARNING: If there are any portions of the display
missing or appearing dim, or if a Low Battery condi-
tion is indicated, return your Versa to an Authorized
Oceanic Dealer for a complete evaluation before at-
tempting to use it.
Fig. 48 - Orientation of Hatch Ring
Fig. 49 -Ring Installation
Fig. 50 -Ring Installation (alternate)
