6.DRIVE TRAIN
6-
8
Check the ring at teh end of drive shaft. If
wear is apparent, replace the wear ring.
Check if the bearing in kunckle move freely
and smoothly. If not, replace them.
Installation
Apply grease to the splines and insert the
end of drive shaft in differential and pull
joint a little to make sure that the stop ring
is locked in differential side gear groove.
Insert the other end of drive shaft in the
knuckle and install the knuckle to the upper
suspension arm.
Install all other removed parts.
Ensure tighten the bolts to the specified torque.
Installation location
Specifications (mm)
Torque N.m(kgf.m)
Mounting nut of wheel rim
M10
60(6.1)
Nut of wheel hub
M22
300(30.6)
Bolt of PARK brake caliper
M10
80(8.2)
