2.PERIODIC MAINTENANCE
2-
ENGINE OIL PRESSURE
Check the engine oil pressure periodically. This will give a good indication of the condition of
the moving parts. The engine oil pressure test should be done with a warm engine 90℃ and the
recommended oil.
Lift the rear cargo bed.
Remove the oil pressure switch wire
connector and switch on the right of engine.
Install oil pressure gauge and adapter hose.
Start engine on idle speed.
The engine oil pressure should be within the
following values.
Remove oil pressure gauge and adapter hose.
Installation oil pressure switch to
12 N.m(8.86Lbf.ft) and the oil pressure switch
wire connector.
Lower the rear cargo bed.
SUSPENSION SYSTEM
Check suspension arm for:cracks/pitting/bending/distortion.
Check suspension arm abnormal play:side to side/up and down.If any play is detected,inspect
bushings and cushions.
Check ball joint for:dammage/pitting/play.
Check ball joint bellows for:damage/cracks.
Lubricate both suspension arms with lithium-soap based grease. There are grease fittings on
each suspension arm. Check operation and for leakage.
