1.GENERAL INFORMATION
1-
3
TECHNICAL SPECIFICATIONS
Item
Parameter
Dimensions
UTV1000-7
Overall length
3339mm(131.457in)
Overall width
1782mm(70.157in)
Overall height
1935mm(76.18in)
Seat height
517mm(20.354in)
Wheelbase
2322mm(91.417in)
Ground clearance
318mm(12.52in)
Engine
Type
Two-cylinder, 4-stroke,SOHC, water cooling
Number of valves
8(mechanical adjustment)
Cylinder diameter
91 mm(3.583in)
Piston stroke
75 mm(2.953in)
Compression ratio
10.3：1
Displacement
976cc
Maximum power
637Kw/6500rpm
Maximum torque
100N.m/5500 rpm
Idle speed
1250rpm
Lubrication
Type
Wet tank lubrication, oil filters can be changed
Oil pressure
0.07-0.25MPa at 1250rpm
Type of oil
SAE10W-50/SJ
Oil quantity
2200mL
Replacement of
capacity
2000mL
Fuel
Type
Unleaded gasoline only 93# or higher
Fuel pressure
350 kpa
Fuel tank capacity
48L
Valve clearance
Intake
0.06 to 0.10mm(0.0024in to 0.0039in)
Exhaust
0.11 to 0.15mm(0.0039in to 0.0059in)
Diameter of valve rod (IN)
New
4.966 to4.980mm(0.196in to 0.196in)
Service limit
4.930mm(0.194in)
Diameter of valve rod (EX)
New
4.956 to 4.970mm(0.195in to 0.1957in)
Service limit
4.930mm(0.194in)
Valve seat contact width (IN)
New
1.05 to 1.35mm(0.0413in to 0.053in)
Service limit
1.80mm(0.0709in)
Valve seat contact width (EX)
New
1.25 to 1.55mm（0.0492in to 0.061in）
Service limit
2.00mm(0.0787in)
Valve guide diameter
New
4.998to 5.018mm(0.1968in to 0.1976in)
Service limit
5.050mm(0.1988in)
Free length of valve spring
New
40.81mm(1.607in)
Service limit
39.00mm(1.5354in)
