1.GENERAL INFORMATION
1-
4
Rocker arm bore diameter
New
12 .036to 12.050mm(0.4739in to 0.4744in)
Service limit
12.060mm(0.4748in)
Rocker arm shaft diameter
New
12.00 to 12.018mm(0.4724in to 0.473in)
Service limit
11.990mm(0.472in)
Piston measurement
New
90.950 to 90.966mm(3.5807in 3.5813in)
Service limit
90.850mm(3.576in)
Cylinder measurement
Size “A”
91.955 to 91.003mm(3.6203in to 3.5830in)
Size “B”
91.0031 to 91.010mm(3.5830in)
Intake cam height
New
32.96 to 33.16mm(1.2976in to 1.3055in)
Service limit
32.94mm(1.2969in)
Exhaust take cam height
New
32.86mm to 33.06mm(1.2937in to 1.3016in)
Service limit
32.84mm(1.2929in)
Crankshaft main journal
diameter
New
42.024 to 42.040mm(1.6545in to 1.6551in)
Service limit
42.000mm(1.6535in)
Crankshaft radial clearance
Service limit
0.06mm(0.0024in)
Crankshaft deflection
Service limit
0.07mm(0.0028in)
Crankshaft pin diameter
New
41.986 to 42.010mm(1.653in to 1.654in)
Service limit
41.967mm(1.6522in)
Connecting rod big end radial
clearance
Service limit
0.09mm(0.0035in )
Connecting rod small end
diameter
New
22.010 to 22.020mm(0.8665in to 0.8669in)
Service limit
22.050mm(8.681in)
Piston pin diameter
New
21.996 to 22.00mm(0.8660in to 0.8661in)
Service limit
21.980mm(0.8654in)
Spark plug
Type/manufacturer
NGK CPR8EA-9
Gap
0.7-0.9mm(0.0276-0.0354in )
Transmission type
CVT(Continuously Variable Transmission)
Continuously variable ratio
0.63to3.06
Drive belt width
Service limit
30.00mm(1.1811in)
Gearbox type
Dual range(H/L) with park, neutral and reverse
Gearbox oil
Capacity
450mL(GL-4-90)
Gear ratio
H
3.36
L
5.84
R
7.15
Cooling liquid temperature
thermostat
Valve opening
65C◦
Fan opening
82C◦
Magneto generator output
520W@6000rpm
Crankshaft position sensor value of resistance
774 to 946 Ω@20℃
Tire
Type
Tubeless
Pressure
97 to 124KPa
Size Front
27×9–14(Rim 14×7.5)
Size Rear
27×11–14(Rim 14×9)
