1.GENERAL INFORMATION
1-
TIGHTENING TORQUE
Locking devices ( e.g.: locking tabs, elastic stop nuts ,self-locking fasteners ,etc.) must be
installed or replaced with new ones, where specified. If the efficiency of a locking device is
impaired, it must be renewed.
In order to avoid a poor assembling, tighten screws, bolts or nuts in accordance with the
following recommended torque value:
Grade
Torque( N·m)
M6
M8
M10
M12
M14
M16
4.6
45
1012
2025
3645
5570
90110
5.6
57
1215
2532
4555
7090
110140
6.8
79
1723
3345
5878
93124
145193
8.8
912
2230
4559
78104
124165
193257
10.9
1316
3036
6578
110130
180201
280330
12.9
1621
3851
75100
131175
209278
326434
CAUTION
As for important tightening torques , please refer to following standards.
Installation location
Specifications (mm)
Torque N.m(kgf.m)
Fastening bolt of engine
M10
60-65(44.3-48)
Fastening nut of suspension arm
M12
78-100(57.6-73.8)
Bolt of rear shock absorber
M12
78-100(57.6-73.8)
Bolt of front shock absorber
M10
60-65(44.3-48)
Fastening nut of wheel rim
M12
90-110(66.4-81.2)
Nut of wheel hub
M22/M24
280-300(206.7-221.4)
Bolt of rear brake/stop pump (calipers)
M10
60-65(44.3-48)
Bolt of brake/stop disc
M8
24-28(17.7-20.7
Bolt of front brake/stop pump (calipers)
M10
60-65(44.3-48)
Lock nut of steering rod
M12
120-140(88.6-103.3)
Lock bolt of steering gearbox
M12
140(103.3)
Bolt of exhaust pipe
M8
18-26(13.3-19.2)
Fastening nut of rear differential
M10
80(59)
Fastening nut of front differential
M10
80(59)
Bolt of front propeller shaft flange
M8
35-40(25.8-29.5)
Bolt of front propeller shaft flange
M10
70-80(51.7-59)
Spark plug
M12
18(13.3)
Be sure to use the proper tightening torque for the proper strength grade. Always torque
screws, bolts and / or nuts in a crisscross sequence.
