1.GENERAL INFORMATION
1-
7
Water temperature sensor
M12
16(11.8)
Oil pressure switch
M10
12.5(9.2)
Adjusting nut of valve clearance
M6
12(8.9)
Main pulley bolt
M12
100(73.8)
Driven pulley bolt
M10
60(44.3）
Magneto flywheel bolt
M16
150(110.7)
Magneto stator bolt
M6
12.5(9.2)
One way bolt
M8
30(22.1)
Engine oil drain plug
M12
20(14.76)
Gearbox oil drain plug
M12
20(14.76)
Decompression valve plug
M22
20(14.76)
Cylinder head bolt
M10
60(4.4）
Cylinder head bolt
M6
12.5(9.2)
Connecting rod bolt
M8
50(36.9)
Timing chain wheel bolt
M8
30(22.1)
Front output shaft flange bolt
M8
30(22.1)
Rear output shaft flange bolt
M10
60(4.4）
