OEG KSW-E - TEMPERATURE AND DATA SYMBOLS; WARNING SYMBOLS

10
User and settings manual
ENG
TEMPERATURE AND OTHER DATA SYMBOLS
Symbol Description
Exceeded temperature
Error
MAX
Exceeded maximum or limit temperature
Sensor is not connected
Sensor is disconnected
Sensor is in short circuit
WARNING SYMBOLS
Symbol Description
Solar collectors’ temperature
Temperature of domestic hot water tank or heat accumulator - bottom
Temperature of domestic hot water tank or heat accumulator - top
Liquid fuel boiler temperature
Solid fuel boiler temperature
Pellet boiler temperature
Outdoor temperature
Swimming pool water temperature
Stand- pipe or return- pipe temperature
Measured temperature
Set point or calculated temperature
T1, T2, T3, T4, T5
Temperature sensors T1, T2, T3, T4 and T5
Hydraulic scheme number
