ENG
27
User and settings manual
DATA OVERVIEW
In the menu “DATA OVERVIEW” there are icons to access the following data on control-
ler performance:
NUMERIC AND GRAPHIC REVIEW OF ACQUIRED ENERGY
There is an extract of all acquired energy by years and energy acquired in the last week.
OUTPUT’S OPERATION TIME COUNTERS
Counters of controller’s outputs operation time.
SPECIAL SERVICE DATA
Intended for diagnostics for technical service.
You can move among numeric reviews and graphs of acquired energy by
pressing buttons and .
DIAGRAMS OF MEASURED TEMPERATURES T1, T2, T3, T4 and
T5
An extract of registered temperatures for temperature sensors from T1 to T5.
You can move among graphs of particular sensors by pressing the button .
By pressing buttons and you can move along the time axis of
the graph. By pressing the button you can change the span of temperature
review on the graph.
