EN-156 EXPLORER BALANCES
Data sent from the Interface is in standard ASCII format terminated with a [CRLF] (carriage return-line feed).
The output format is as follows:
[weight] 10 characters (right justified)
[space] 1 character
[unit] 5 characters max (left justified)
[space] 1 character
[stability indicator] 1 character “?” when unstable or below min-weight, blank when stable
[space] 1 character
[legend] 10 character TOTAL, hh:mm:ss (time interval), etc.
[CR] 1 character
[LF] 1 character
Output examples: (Note: * and _ indicate spaces)
*****192.21_g – Manual, Continuous or On-Stable printing
*******0.01_g_? unstable reading
*******0.01_g___ 00:00:00 – Interval Printing (example:15sec interval)
*****176.30_g_?_00:00:15 unstable reading
*****192.08_g___00:00:30
*****192.21_g
*****207.80_g_TOTAL – Accumulate Mode (Manual printing only)
