Oki C110 User Manual

About the Control Panel1-6
About the Rotate Toner KEY
The Rotate Toner key allows you to switch the printer from normal operation
mode to Change Toner mode, Eject All Toner mode or Print Head Cleanup
mode.
The mode that the printer enters depends on how long the Rotate Toner key
is held down.
" When the printer is switched to any of these operation modes, the
magenta toner indicator lights up.
The Rotate Toner key is used in the following situations.
 When replacing a toner cartridge
 When replacing all toner cartridges at the same time
 When cleaning the print head window
When replacing a toner cartridge
Press the Rotate Toner key.
The printer enters Change Toner mode.
" For details on replacing a toner cartridge, refer to “Replacing a Toner
Cartridge” on page 5-4.
" To return to normal operation mode from Change Toner mode, press
the Cancel key.
Length of time that
the Rotate Toner key
is held down
Mode that the printer
enters
Indicators on the
control panel
Less than 5 seconds Change Toner mode -
5 to 10 seconds Print Head Cleanup
mode
All indicators blink once
after the key has been
held down for 5 sec
-
onds.
More than 10 seconds Eject All Toner mode All indicators flash once
after the key has been
held down for 10 sec
-
onds.

Oki C110 Specifications

General

Color	Yes
Duplex printing	No
Maximum resolution	600 x 1200 DPI
Time to first page (black, normal)	13 s
Time to first page (color, normal)	22 s
Print speed (black, normal quality, A4/US Letter)	19 ppm
Print speed (color, normal quality, A4/US Letter)	5 ppm
Internal memory	16 MB
Sound power level (standby)	29 dB
Sound pressure level (printing)	51 dB
Total input capacity	200 sheets
Total output capacity	100 sheets
Maximum print size	216 x 356 mm
ISO A-series sizes (A0...A9)	A4, A5
ISO B-series sizes (B0...B9)	B5
Maximum ISO A-series paper size	A4
Supported media weight(s)	60/209 g/m²
Compatible operating systems	Windows 2000 / XP / XP x64 / Vista (32 bit) / Vista (64 bit) / Server 2003 / Server 2003 x64 / Server 2008 / Server 2008 x64
Maximum operating temperature range (T-T)	10 - 35 °C
Recommended operating temperature range (T-T)	15 - 25 °C
Maximum duty cycle	250 pages per month
Sustainability certificates	ENERGY STAR
Power consumption (printing)	440 W
Power consumption (PowerSave)	14 W
Storage temperature (T-T)	-20 - 40 °C
Storage relative humidity (H-H)	10 - 95 %
Operating relative humidity (H-H)	15 - 85 %

Weight and Dimensions

Dimensions (WxDxH)	396 x 380 x 275 mm
