42615101TH Rev.8 57 /
Oki Data CONFIDENTIAL
(2) Second Tray Installation(This is unavailable for C3200n/C5510.)
A second tray expands the printer’s paper holding capacity, and can hold 530 sheets of 70-kg
paper in it. A printer equipped with the tray can continuously print those 930 sheets of the
paper, using the paper cassette and MP tray that are standard on the printer.
Type: MLTRY-C4C1 Type:
Power Off Printer to Remove Power Supply Cord
Note!
Installing the second tray with the printer powered on may cause a problem with the
printer.
OI
Place Printer on Second Tray Unit
Note!
Each printer weighs about 25 kg. Lift it by more than one person.
(1) Align the cuts on the bottom surface of the printer with the protrusions of the second tray
unit.
(2) Put the printer on the second tray unit carefully.
For removing the second tray, reverse the installation procedure.
Protrusion
Cut on Bottom
Surface of Printer
To Next Page
