44205401TH Rev.1
100 /
Oki Data CONFIDENTIAL
5. Maintenance Menu
Table 5-3 SWITCH SCAN details
<Item having no function> Asterisk mark (*)
is displayed in the lower row of display area.
* 1: “L” is displayed when the cover is opened.
Display area, upper row
1 2 3 4
Details
Display area,
lower row
Details
Display area,
lower row
Details
Display area,
lower row
Details
Display area,
lower row
PAPER ROUTE : PU Entrance sensor 1
H: No paper
L: Paper exists
Entrance sensor 2
H: No paper
L: Paper exists
Write sensor
H: No paper
L: Paper exists
Exit sensor
H: No paper
L: Paper exists
TONER SENS Toner sensor K
H: Light is interrupted
L: Reflected
Toner sensor Y
H: Light is interrupted
L: Reflected
Toner sensor M
H: Light is interrupted
L: Reflected
Toner sensor C
H: Light is interrupted
L: Reflected
CVO UP_LU_FU Cover open switch
H: Close
L: Open
ST_FD_FU JOBOFF
Stacker down
sensor
H: No paper
L: Paper exists
REG L/R_OHP_WG
Color registration
sensor L
AD value:
***H
Color registration
sensor R
AD value:
***H
HT THERMISTER
Fuser thermistor,
upper sensor
AD value:
***H
Fuser thermistor,
lower sensor
AD value:
***H
Fuser thermistor,
upper sensor, side
AD value:
***H
Heater frame
thermistor
AD value:
***H
HUM_TEMP_DEN Humidity sensor
AD value:
***H
Humidity sensor
AD value:
***H
Humidity sensor (k)
AD value:
***H
Humidity sensor
(YMC)
AD value:
***H
BELT_T Belt thermistor
AD value:
***H
ID UP/DOWN GREY GREY ID UpDown Sns
H: Down
L: Up
RFID COLOR*1 RFID antenna K
UID:
***H
RFID antenna Y
UID:
***H
RFID antenna M
UID:
***H
RFID antenna C
UID:
***H
T1 PE_PNE_CVO
Tray 1 paper end
sensor
H: No paper
L: Paper exists
T1 CASETTE SIZE*1 Size setting switch 1 Port level H, L Size setting switch 2 Port level H, L Size setting switch 3 Port level H, L Size setting switch 4 Port level H, L
T2 PE_PNE_CVO_CA
Tray 2 paper end
sensor
H: No paper
L: Paper exists
T2 HOP_LF_FED 2nd-Hopping Sns
H: No paper
L: Paper exists
Tray 2 entrance
sensor
H: No paper
L: Paper exists
T2 CASETTE SIZE*1 Size setting switch 1 Port level H, L Size setting switch 2 Port level H, L Size setting switch 3 Port level H, L Size setting switch 4 Port level H, L
T3 PE_PNE_CVO
Tray 3 paper end
sensor
H: No paper
L: Paper exists
T3 HOP_LF_FED 3rd-Hopping Sns
H: No paper
L: Paper exists
Tray 3 entrance
sensor
H: No paper
L: Paper exists
T3 CASETTE SIZE Size setting switch 1 Port level H, L Size setting switch 2 Port level H, L Size setting switch 3 Port level H, L Size setting switch 4 Port level H, L
DUP IN_RA_FNT
Duplex (2-sided
printing) entrance
sensor
H: No paper
L: Paper exists
Duplex (2-sided
printing) front
sensor
H: No paper
L: Paper exists
DUP SK_CVO
Duplex (2-sided
printing) bottom
sensor
H: No paper
L: Paper exists
Duplex (2-sided
printing) cover
sensor
H: Close
L: Open
