5. Maintenance Menu
5.3.1.8 Consumable item counter display
This self-diagnostic menu is used to display the consumption status of the consumable
items.
1. Ent
er the ordinary self-diagnostic mode and press the MENU+, MENU- key
until "CONSUMABLE STATUS" is displayed in the display area. (Pressing the
MENU+ key increments the test item and pressing the MENU- key decrements
the test item.)
2. W
he
n the MENU+, MENU- key is pressed, consumption statuses of the
consumable items are displayed in order. (Pressing the ONLINE or CANCEL
key is invalid.)
3. Pressing the BACK ke
y terminates the test. (Returns to the status of step 1.)
Display area,
upper row
Display area,
lower row
Format Unit Details
K-ID UNIT ********IMAGES DEC Images Number of rotations from the time
when the ID UNITs of respective
colors are installed up to the
present time is displayed after
converting them to the units of A4
3Page/Job.
Y-ID UNIT ********IMAGES DEC Images
M-ID UNIT ********IMAGES DEC Images
C-ID UNIT ********IMAGES DEC Images
FUSER UNIT ********PRINTS DEC Prints Number of copies from the time of
installation of a new fuser unit up
to the present time is displayed.
TR BELT UNIT ********IMAGES DEC Images Number of copies from the time of
installation of a new belt unit up to
the present time is displayed.
K-TONER
(FULL)
********% DEC % Amount of consumption of the
respective toners is displayed.
Y-TONER
(FULL)
********% DEC %
M-TONER
(FULL)
********% DEC %
C-TONER
(FULL)
********% DEC %
M-WASTE TNR
CNT
********TIMES DEC Times Amount of waste toner is
displayed.
* When the times reaches 32 times
or more, the waste toner full is
issued.
C-WASTE TNR
CNT
********TIMES DEC Times
Display area,
upper row
Display area,
lower row
Format Unit Details
K-STC MODE
CNT
********TIMES DEC Times Number of print dot counts of the
toner of the respective colors are
displayed.
(Accumulative value since start of
the system operation.)
Y-STC MODE
CNT
********TIMES DEC Times
M-STC MODE
CNT
********TIMES DEC Times
C-STC MODE
CNT
********TIMES DEC Times
K OVER RIDE
CNT
********TIMES DEC Times Number of times of continues
of the toner cartridge of the
respective colors are displayed.
Y OVER RIDE
CNT
********TIMES DEC Times
M OVER RIDE
CNT
********TIMES DEC Times
C OVER RIDE
CNT
********TIMES DEC Times
