Oki C711 - Page 102

44205401TH Rev.1
102 /
Oki Data CONFIDENTIAL
5. Maintenance Menu
Table 5-4
Unit name display Drive restriction condition Remarks
ID MOTOR To be driven when all of the ID (K/Y/M/C) are
removed.
−
BELT MOTOR To be driven when all of the ID (K/Y/M/C) are
removed.
−
FUSER_RLS − −
REGIST MOTOR − −
T1 HOPPING MOTOR − −
FRONT MOTOR − −
REGIST SHUTTER − −
EXIT SOLENOID − −
DUPLEX MOTOR − −
DUPLEX CLUTCH − −
T2 HOPPING MOTOR − OPTION
T2 FEED CLUTCH − OPTION
T3 HOPPING MOTOR − OPTION
T3 FEED CLUTCH − OPTION
ID UP/DOWN TOP/FRONT cover closed status −
LV FAN TEST − −
FUSER FAN TEST − −
DUPLEX FAN TEST − OPTION
ID FAN TEST − −
Note! Display while ID Up/Down execution is in progress
MOTOR & CLUTCH TEST
ID UP/DOWN ***
*** Number of times of execution
Display when the REGIST SHUTTER [ENTER] key is pressed long
MOTOR & CLUTCH TEST
SHT ***
*** Number of times of execution
