44205401TH Rev.1
130 /
Oki Data CONFIDENTIAL
7. Troubleshooting and repair procedure
Panel display
(The mark indicates no
message in the upper row.)
ON
LINE
lamp
Inspection
lamp
Details
Checking Sectors
nnn%
Off Off Displays that a sector of SD Card is being checked.
Check process of the sector is valid to start from
"Storage Setup"-"Check All Sectors" of Boot Menu.
nnn
Percentage of checked capacity
Program Update Mode Off Off Indicates that the printer has entered in the
dedicated mode for upgrading the NIC program
(controller firmware) version.
Wait a Moment
Program Data Received
Off Blink Indicates that reception of the NIC program data
for upgrading is in progress.
Wait a Moment
Program Data Received
OK
Off Off Indicates that reception of the NIC program data
for upgrading is complete.
Check Data
Program Data Receive
Error
<nnn>
Off On Indicates that an error has occurred during
reception of the NIC program data for upgrading.
%DLCODE%
1
: Size error
2 : Checksum error
3
: Printer model number error
4 : Module I/F version error
5 : FAT version error
Wait a Moment
Program Data Writing
Off Blink Indicates that writing of the NIC program data for
upgrading is in progress.
Power Off/On
Program Data Writing OK
Off Off Indicates that writing of the NIC program data for
upgrading is in complete.
Check Data
Program Data Write Error
<nnn>
Off On Indicates that an error has occurred during writing
of the NIC program data for upgrading.
%DLCODE%
1
: Memory allocation error
2 : Download file error
3
: Device free space acquisition error
4 : Device insufficient free space error
5 : File write error
6
: CU-F/W mismatch error
Panel display
(The mark indicates no
message in the upper row.)
ON
LINE
lamp
Inspection
lamp
Details
PU Flash Error Off Off Indicates that the PU firmware has started up
in the Loader mode. It is indicated when the PU
firmware has returned "00.00.00" against the
Leisus command "VERSIONR 01H" requesting
(PU) firmware version information supplied from
the CU firmware at power-on. When initialization is
finished, it is switched to the Priority 251 status.
This error can occur in the user environment. If
this error occurs, maintenance by a maintenance
engineer is required. (Same as S/C)
Communication Error Off Off Indicates that communication with the PU firmware
has failed. This error can occur in the user
environment. If this error occurs, maintenance by a
maintenance engineer is required. (Same as S/C)
Status Mode Off Off Indicates that the printer has started in the ON
LINE mode always. When a printer starts up in
this mode, it processes the data (job) from outside
(host) even when an error occurs if a printer has
entered the ON LINE mode once.
Error and warning are displayed on the panel.
A printer can enter in this mode if the power of a
printer is turned on while pressing the switches of
<Enter> + <Back> + <Down> all simultaneously.
Because this pattern of pressing the multiple
switches at the same time at power-on is not
disclosed to user, this status will not occur in the
user environment.
To Next Page
