Oki C711WT Network Guide

Printing from windows > 31
P RINTING FROM WINDOWS
O VERVIEW
This chapter provides guidelines on how to print over the network from various Microsoft
Windows platforms. There are numerous ways of printing from Windows and the exact set-
up will vary depending upon your environment. There are also numerous versions of
Windows, which can be configured as either a client, server or both.
Although there are many variants of Windows, the principles of network printing are the
same. Microsoft provides on-line help with all of their operating systems and this is a good
reference point for the exact details of each configuration option within Windows.
I NSTALLING A NETWORK PRINTER
There are two ways to set up a Network Printer:
> Install automatically, using the Oki Driver Installer
> Install it yourself using the Add Printer Wizard
U SING THE O KI D RIVER I NSTALLER
The Oki Driver Installer program searches for compatible printers on the Network, then
installs and configures the printer drivers with the correct port settings automatically.
Using the Oki Driver Installer program, you can install to the following connected printer
types:
1. Locally connected printers
> USB port
> Parallel port (if available)
2. Networked printers
> Directly connected (peer-to-peer) printers via TCP/IP
The Microsoft standard TCP/IP is installed and configured to use Port 9100 with the
printer’s IP address.
> Printers not directly connected, but shared via a PC (Client Server)
Why use the Oki Driver Installer?
> Automatically discovers printers on the Network (TCP/IP)
> Installs driver and correctly assigns the appropriate port and IP address
> Allows easy configuration and sharing of the printer with other Network users
> Automatically configures the printer driver with the appropriate hardware device
options such as, additional paper trays, etc. (via the Oki Network Extension
software)
NOTE
Not all utilities, features or protocols are supported by every operating
system. Please check with your support website for latest information.

Oki C711WT Specifications

General

Color	Yes
Duplex printing	No
Print technology	LED
Resolution color	600 x 600 DPI
Maximum resolution	1200 x 600 DPI
Time to first page (black, normal)	9 s
Print speed (black, normal quality, A4/US Letter)	34 ppm
Printing colors	Cyan, Magenta, White, Yellow
Maximum duty cycle	30000 pages per month
Number of print cartridges	-
Page description languages	PostScript 3
Maximum internal memory	768 MB
Sound power level (standby)	37 dB
Sound pressure level (printing)	54 dB
Total input capacity	630 sheets
Total output capacity	350 sheets
Maximum input capacity	1690 sheets
Total number of input trays	1
Maximum number of input trays	3
Multi-Purpose tray input capacity	100 sheets
Envelopes sizes	9, 10, C5, DL
Maximum print size	210 x 297 mm
Paper tray media types	Envelopes, Labels, Plain paper
Paper tray media weight	64 - 220 g/m²
ISO A-series sizes (A0...A9)	A4, A5, A6
ISO B-series sizes (B0...B9)	B5
Maximum ISO A-series paper size	A4
Multi-Purpose Tray media weight	64 - 250 g/m²
Standard interfaces	Ethernet, USB 2.0
USB 2.0 ports quantity	USB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
Mac operating systems supported	Mac OS X 10.4 Tiger, Mac OS X 10.5 Leopard, Mac OS X 10.6 Snow Leopard, Mac OS X 10.7 Lion
Server operating systems supported	Windows Server 2003, Windows Server 2003 x64, Windows Server 2008, Windows Server 2008 R2, Windows Server 2008 x64
Windows operating systems supported	Windows 7 Home Premium, Windows 7 Home Premium x64, Windows 7 Professional, Windows 7 Professional x64, Windows 7 Starter, Windows 7 Starter x64, Windows 7 Ultimate, Windows 7 Ultimate x64, Windows Vista Business, Windows Vista Business x64, Windows Vista Home Basic, Windows Vista Home Basic x64, Windows Vista Home Premium, Windows Vista Home Premium x64, Windows Vista Ultimate, Windows Vista Ultimate x64, Windows XP Home, Windows XP Home x64, Windows XP Professional, Windows XP Professional x64
AC input voltage	220 - 240 V
AC input frequency	50 - 60 Hz
Power consumption (standby)	1.2 W
Power consumption (printing)	600 W
Power consumption (PowerSave)	15 W
Storage temperature (T-T)	-10 - 43 °C
Operating temperature (T-T)	10 - 32 °C
Storage relative humidity (H-H)	10 - 90 %
Operating relative humidity (H-H)	20 - 80 %
Power supply type	AC
Networking features	Fast Ethernet
Networking standards	IEEE 802.3, IEEE 802.3u
Display	LCD
Product color	Gray

Weight and Dimensions

Dimensions (WxDxH)	435 x 546 x 389 mm
