Oki C711WT Network Guide

Mac OS X > 45
2. Click Add….
3. Click the IP Printer button.
4. From the Protocol menu, choose Line Printer Daemon – LPD.
5. Enter the printer’s IP address in Address.
To find the printer's IP address, you can print a configuration page from the printer's
operator panel. Refer to “Configuration settings” on page 7.
6. Check the correct PPD file for your printer is selected in the Print Using menu.
7. Click Add....
8. You will be prompted to configure any additional printer hardware options. If your
printer has options such as second tray, switch on the relevant options.
9. Click Continue.
10. Quit Printer Setup Utility.
P ANTHER (10.3)
Rendezvous
If you have not already done so, run the Oki software installer before following the steps below.
1. Start the Printer Setup Utility.
This is located in the Applications > Utilities folder.
2. Click Add....
3. From the pop-up menu, choose Rendezvous.
4. Select the printer you wish to connect to.
5. Click Add.
6. Click the Printer Setup Utility menu, and choose Quit Printer Setup Utility.
After adding the printer, you should configure printer hardware options. Refer to
“Configuring printer hardware options” on page 47.
NOTE
If your printer is already listed, your Mac may already have discovered the
printer before you installed the Oki software. In this case, the printer may be
using the incorrect PPD file or may not have the correct hardware options
configured. You should delete the printer, quit Printer Setup Utility, and re-
launch the utility before continuing.

Oki C711WT Specifications

General

Color	Yes
Duplex printing	No
Print technology	LED
Resolution color	600 x 600 DPI
Maximum resolution	1200 x 600 DPI
Time to first page (black, normal)	9 s
Print speed (black, normal quality, A4/US Letter)	34 ppm
Printing colors	Cyan, Magenta, White, Yellow
Maximum duty cycle	30000 pages per month
Number of print cartridges	-
Page description languages	PostScript 3
Maximum internal memory	768 MB
Sound power level (standby)	37 dB
Sound pressure level (printing)	54 dB
Total input capacity	630 sheets
Total output capacity	350 sheets
Maximum input capacity	1690 sheets
Total number of input trays	1
Maximum number of input trays	3
Multi-Purpose tray input capacity	100 sheets
Envelopes sizes	9, 10, C5, DL
Maximum print size	210 x 297 mm
Paper tray media types	Envelopes, Labels, Plain paper
Paper tray media weight	64 - 220 g/m²
ISO A-series sizes (A0...A9)	A4, A5, A6
ISO B-series sizes (B0...B9)	B5
Maximum ISO A-series paper size	A4
Multi-Purpose Tray media weight	64 - 250 g/m²
Standard interfaces	Ethernet, USB 2.0
USB 2.0 ports quantity	USB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
Mac operating systems supported	Mac OS X 10.4 Tiger, Mac OS X 10.5 Leopard, Mac OS X 10.6 Snow Leopard, Mac OS X 10.7 Lion
Server operating systems supported	Windows Server 2003, Windows Server 2003 x64, Windows Server 2008, Windows Server 2008 R2, Windows Server 2008 x64
Windows operating systems supported	Windows 7 Home Premium, Windows 7 Home Premium x64, Windows 7 Professional, Windows 7 Professional x64, Windows 7 Starter, Windows 7 Starter x64, Windows 7 Ultimate, Windows 7 Ultimate x64, Windows Vista Business, Windows Vista Business x64, Windows Vista Home Basic, Windows Vista Home Basic x64, Windows Vista Home Premium, Windows Vista Home Premium x64, Windows Vista Ultimate, Windows Vista Ultimate x64, Windows XP Home, Windows XP Home x64, Windows XP Professional, Windows XP Professional x64
AC input voltage	220 - 240 V
AC input frequency	50 - 60 Hz
Power consumption (standby)	1.2 W
Power consumption (printing)	600 W
Power consumption (PowerSave)	15 W
Storage temperature (T-T)	-10 - 43 °C
Operating temperature (T-T)	10 - 32 °C
Storage relative humidity (H-H)	10 - 90 %
Operating relative humidity (H-H)	20 - 80 %
Power supply type	AC
Networking features	Fast Ethernet
Networking standards	IEEE 802.3, IEEE 802.3u
Display	LCD
Product color	Gray

Weight and Dimensions

Dimensions (WxDxH)	435 x 546 x 389 mm
