Oki C711WT Network Guide

Printing from windows > 34
Using TCP/IP protocol
When using lpr in UNIX and other TCP/IP environments, please select Yes. To use in
a TCP/IP environment, an IP address should be assigned to the Ethernet card.
If Yes has been selected and TCP/IP is the only working protocol and the IP address
has not already been assigned, you can either obtain an IP address automatically or
assign an IP address.
When Obtain an IP address automatically is selected, the device IP address will
be automatically assigned by the DHCP server. In an environment without a DHCP
server, please assign the IP address manually.
If you are manually assigning an IP address, you need to enter:
> An IP address
> Subnet mask
> Gateway address
9. Click Next.
Using Bonjour protocol
Bonjour is the preferred protocol for printing data from the Macintosh environment.
Using NetBEUI protocol
Using NetBEUI makes it easy to manage your Oki product and print within the
network environment of Windows.
10. When the settings are correct, click Execute. The new settings are transmitted to
the network card but it still operates with pre-transmission settings.
11. Click Finish to validate the new settings.
12. Switch the printer off for 15 seconds and on again.
Now that both Windows and the printer have been configured to use TCP/IP, the next step
is to configure Windows to print to the network printer.
N ET BEUI PROTOCOL
N ETWORK PRINTER SETTINGS
There are two configurable items under NetBEUI within the printer. These can be
configured using the standard set-up utility described in “Device setup” on page 12.
Although there are some differences in configuration options between the various Windows
platforms, the procedure for printing using NetBEUI is the same.
Please ensure the NetBEUI protocol has been installed in Windows. This can be confirmed
by checking the network settings. If NetBEUI has not been installed please refer to the
section below.
The relevant Windows installation CD-ROM may be required and you should follow the on-
screen dialogue box prompts.
COMPUTER NAME NAME ASSIGNED TO THE PRINTER
Workgroup
PrintServer
a
a. Although the workgroup name can be changed, it is recommended
that it remains as PrintServer.
Comment User definable description

Oki C711WT Specifications

General

Color	Yes
Duplex printing	No
Print technology	LED
Resolution color	600 x 600 DPI
Maximum resolution	1200 x 600 DPI
Time to first page (black, normal)	9 s
Print speed (black, normal quality, A4/US Letter)	34 ppm
Printing colors	Cyan, Magenta, White, Yellow
Maximum duty cycle	30000 pages per month
Number of print cartridges	-
Page description languages	PostScript 3
Maximum internal memory	768 MB
Sound power level (standby)	37 dB
Sound pressure level (printing)	54 dB
Total input capacity	630 sheets
Total output capacity	350 sheets
Maximum input capacity	1690 sheets
Total number of input trays	1
Maximum number of input trays	3
Multi-Purpose tray input capacity	100 sheets
Envelopes sizes	9, 10, C5, DL
Maximum print size	210 x 297 mm
Paper tray media types	Envelopes, Labels, Plain paper
Paper tray media weight	64 - 220 g/m²
ISO A-series sizes (A0...A9)	A4, A5, A6
ISO B-series sizes (B0...B9)	B5
Maximum ISO A-series paper size	A4
Multi-Purpose Tray media weight	64 - 250 g/m²
Standard interfaces	Ethernet, USB 2.0
USB 2.0 ports quantity	USB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
Mac operating systems supported	Mac OS X 10.4 Tiger, Mac OS X 10.5 Leopard, Mac OS X 10.6 Snow Leopard, Mac OS X 10.7 Lion
Server operating systems supported	Windows Server 2003, Windows Server 2003 x64, Windows Server 2008, Windows Server 2008 R2, Windows Server 2008 x64
Windows operating systems supported	Windows 7 Home Premium, Windows 7 Home Premium x64, Windows 7 Professional, Windows 7 Professional x64, Windows 7 Starter, Windows 7 Starter x64, Windows 7 Ultimate, Windows 7 Ultimate x64, Windows Vista Business, Windows Vista Business x64, Windows Vista Home Basic, Windows Vista Home Basic x64, Windows Vista Home Premium, Windows Vista Home Premium x64, Windows Vista Ultimate, Windows Vista Ultimate x64, Windows XP Home, Windows XP Home x64, Windows XP Professional, Windows XP Professional x64
AC input voltage	220 - 240 V
AC input frequency	50 - 60 Hz
Power consumption (standby)	1.2 W
Power consumption (printing)	600 W
Power consumption (PowerSave)	15 W
Storage temperature (T-T)	-10 - 43 °C
Operating temperature (T-T)	10 - 32 °C
Storage relative humidity (H-H)	10 - 90 %
Operating relative humidity (H-H)	20 - 80 %
Power supply type	AC
Networking features	Fast Ethernet
Networking standards	IEEE 802.3, IEEE 802.3u
Display	LCD
Product color	Gray

Weight and Dimensions

Dimensions (WxDxH)	435 x 546 x 389 mm
