- 18 -
Preparing Your Printer
1
1. Setup
4 Remove the protective sheets from four
image drums.
(1) Place an image drum on a
newspaper. Remove a tape (6) stuck
on a protective sheet (5) and open it.
6
5
(2) Pull out a protective sheet to the
direction of the arrow.
Note
● Do not turn the blue lever of the toner cartridge.
5 Put all four image drums back into a
printer.
6 Turn the blue lever (7) of the toner
cartridge backward until its top aligns on
the
mark.
Turn the levers of all four 4 toner cartridges.
7
7 Close the output tray (4) by pushing the
both sides of the cover rmly.
4
8 Close the front cover (2).
Note
● The front cover cannot be closed securely if the
output tray is not closed.
● When the error message that the top or front cover
is open does not disappear from the operator panel’s
display screen, make sure they are closed securely.
2
To Next Page
