- 17 -
Preparing Your Printer
1
1. Setup
●● Preparing Your Printer
This section explains how to unpack your printer and how to turn it on and off.
Unpacking
CAUTIO
It may cause injury!
● At least two people are needed to lift the printer
safely because it weighs about 37 Kg or 40 Kg.
Note
● Be sure to use the consumables or maintenance units
provided with this printer at rst. Otherwise, the life of the
consumables or maintenance units may not be displayed
correctly, or you may not be able to use them later.
● The image drum (the green tube) is very delicate. Handle
it carefully.
● Do not expose the image drum to direct sunlight or very
bright interior light (approximately more than 1500 lux).
Even under the normal interior light, do not leave it for
more than 5 minutes.
● Packaging and cushioning material are needed if
transporting the printer. Do not throw them away.
1 Remove your printer from the box and
remove all cushioning materials and the
plastic bag from your printer.
2 Remove the two strips of protective tape
(1) at the back of your printer.
1
Installing Consumables
1 Insert your nger into the recess on
the right side of the printer and pull the
front cover open lever (1) to open the
front cover (2) forward.
Note
● Open the front cover gently. If opening rapidly, an MP
tray may open.
1
2
2 Press the output tray open button (3)
and open the output tray (4).
3
4
3 Take out all four image drums from the
printer.
To Next Page
