Oki C834 User Manual

- 127 -
7. Maintenance
cartridge and image drum color label align. Then insert the right side gently
into place.
12
Turn the toner cartridge lock lever (blue) (6) of the toner cartridge backward
until its top align on the mark while pressing the toner cartridge to attach
the toner cartridge to the image drum.
You will hear a click when it is locked in place.
13
Check the label color of the new image drum and place the drum into the
machine.
• Use extra care when handling the image drum (the green cylinder), because it is fragile.
14
Close the output tray (4) by pushing the center of the output tray (4) firmly.
15
Close the front cover (2).

Oki C834 Specifications

General

Print Technology	LED
Maximum Paper Size	A3
Processor	800 MHz
Operating Systems Supported	Windows, Mac OS, Linux
Dimensions	449 x 552 x 360 mm
Weight	37 kg
Print Resolution	1200 x 600 dpi
Duplex Printing	Yes
Memory	1 GB
Connectivity	USB, Ethernet
Interface	USB, Ethernet
Media Size	A6 to A3
