Oki MB760dnfax Service Manual

45641001TH Rev.1
5-37 /
Oki Data CONFIDENTIAL
[EAF4] Paper support HP abnormality
Classification Error content
Finisher related service call Paper support HP abnormality
Check item Measures
Paper support home position
sensor
• Sensorcheck(S6)
• Connectorcheck(P7-13)
• Harnesscheck
Paper support motor • Motorcheck(M6)
• Connectorcheck(P6-1)
• Harnesscheck
Finisher control PC board • Boardcheck
• Connectorcheck(J6,J7)
• Harnesscheck
Parts to be replaced Remark
Paper support home position
sensor
Paper support motor
Finisher control PC board
[EAF5] Lever path HP abnormality
Classification Error content
Finisher related service call LeverpathHPabnormality
Check item Measures
Leverpathhomeposition
sensor
• Sensorcheck(S15)
• Connectorcheck(P7-4)
• Harnesscheck
Leverpathmotor • Motorcheck(M10)
• Connectorcheck(P18-1)
• Harnesscheck
Finisher control PC board • Boardcheck
• Connectorcheck(J7,J18)
• Harnesscheck
Parts to be replaced Remark
Leverpathhomeposition
sensor
Leverpathmotor
Finisher control PC board
