Oki MB760dnfax Service Manual

45641001TH Rev.1
5-38/
Oki Data CONFIDENTIAL
[EAF6] Front alignment HP abnormality
Classification Error content
Finisher related service call Front alignment HP abnormality
Check item Measures
Front alignment plate home
position sensor
• Sensorcheck(S4)
• Connectorcheck(P8-3)
• Harnesscheck
Front alignment motor • Motorcheck(M4)
• Connectorcheck(P6-12)
• Harnesscheck
Finisher control PC board • Boardcheck
• Connectorcheck(J6,J8)
• Harnesscheck
Parts to be replaced Remark
Front alignment plate home
position sensor
Front alignment motor
Finisher control PC board
[EAF7] Rear alignment HP abnormality
Classification Error content
Finisher related service call Rear alignment HP abnormality
Check item Measures
Rear alignment plate home
position sensor
• Sensorcheck(S5)
• Connectorcheck(P7-5)
• Harnesscheck
Rear alignment motor • Motorcheck(M5)
• Connectorcheck(P5-13)
• Harnesscheck
Finisher control PC board • Boardcheck
• Connectorcheck(J5,J7)
• Harnesscheck
Parts to be replaced Remark
Rear alignment plate home
position sensor
Rear alignment motor
Finisher control PC board
