Oki MC573dn - Page 114

To Next Page

To Previous Page

- 114 -

4. Copy

• [Function Settings] Screen

Item Description

1 Setting display area 1 Displays the current settings for displayed items.

2 Setting display area 2 Displays a list of settings that are not displayed in the setting display

area 1.
