- 128 -

5. Scan

• [Function Settings] > [Profile] Tab

Delete a selected profile on the [Profile] tab.

• [Function Settings] > [Scan Setting] Tab

Item Description

1 Setting display area 1 Displays the current settings for displayed items.

2 Setting display area 2 Displays a list of settings that are not set by items displayed in

setting display area 1.
