- 192 -
9. Troubleshooting
13
Turn the lock levers (g) on the both sides of the belt unit forward.
14
Hold the fuser unit handle and place the fuser unit into the machine.
While setting the fuser unit, be careful not to hit it to the LED head.
15
Tilt the lock levers (f) on the both sides of the fuser unit.
16
Put all four image drums back into the machine.
While setting consumables, be careful not to hit them to the LED head.
To Next Page
