- 21 -
2. Setting Up
9
Push the blue lever on the fuser unit and remove the orange safety stopper
and film.
10
Hold the fuser unit handle and aligning the fuser unit to the grooves behind the
toner cartridges, place the fuser unit into the machine.
While setting the fuser unit, be careful not to hit it to the LED head.
11
Push the levers on the fuser unit to lock.
12
Close the output tray (a) slowly and push the center of the output tray for
confirmation.
If the error message that the output tray is open does not disappear, make sure that the output tray is closed
securely.
To Next Page
