Oki MICROLINE 320 Turbo Maintenance Manual

42089201TH Rev.4 116 /
Oki Data CONFIDENTIAL
OCS
P1P2P0
P3
TD
RD
IF WR
LS245
2764
ROM
8 KB
RD
TD
RAM
8 KB
Driver
+5 VD
10 VAC
+5 V
+9 V
-9 V
+5V
0V
±9 V power
supply circuit
Serial data
control line
Bus line
Control line
ADR latch
Receiver
DB0 to DB9
ADR/data bus
ADR bus
80C51
RST
CN1
Figure B-2-1 Block Diagram

Oki MICROLINE 320 Turbo Specifications

General

Color	No
Built-in barcodes	Code 39
Maximum resolution	288 x 144 DPI
Maximum number of copies	6 copies
Media thickness	0.36 - 0.43 mm
Dimensions (WxDxH)	399 x 355 x 117 mm
Networking features	OkiLAN 6120e 10/100 Base-T
Connectivity technology	Wired
Compatible operating systems	Windows Vista, XP, 2000/ME, 98 & NT 40; UNIX, MS-DOS, Novell
Page description languages	Epson FX
Sound pressure level (printing)	52 dB
Mean time between failures (MTBF)	10000 h
Power consumption (typical)	100 W
Operating temperature (T-T)	5 - 40 °C
Operating relative humidity (H-H)	20 - 80 %
