2.1.3 Initialization
This printer is initialized when the power is turned on or when the I-PRIME-N signal is input
from the host side via the parallel interface.
For the initializing operation, the RST-N signal is first output from the reset circuit to reset the
MPUs and LSIs. When resetting ends, the program starts and the LSIs are reset by MPU via
LSIRST-N. Reset operation by I-PRIME starts program to initialize, but does not reset the MPU.
The program here sets the mode of the LSI including the MPU, checks the memories (ROMs
and RAMs) and, after USB I/F control LSI initialization and USB I/F bus opening, performs
carriage homing operation and LF motor phase setting.
Finally, the program establishes the interface signals (P-I/F: ACK-P signal sending, and S-I/F:
BUSY-N signal off) and lights the SELECT lamp to inform the ready state for receiving to the
host side and ends the initialize operation.
(at USB Ver.)
End
I/F BUSY OFF
Serial
I/F
I/F ACK Send
Parallel
I/F
LF Motor Phase
Initialization
Carriage Homing
RAM Clear
LSI Initial Setting
and I/F Busy ON
USB I/F Bus Open
USB I/F control LSI
Initial
External RAM
CHECK
LSI RESET
ROM CHECK
Internal RAM
CHECK
MPU
Initial Setting
MPU RESET
Start

Oki MICROLINE 320 Turbo Specifications

General

Color	No
Built-in barcodes	Code 39
Maximum resolution	288 x 144 DPI
Maximum number of copies	6 copies
Media thickness	0.36 - 0.43 mm
Dimensions (WxDxH)	399 x 355 x 117 mm
Networking features	OkiLAN 6120e 10/100 Base-T
Connectivity technology	Wired
Compatible operating systems	Windows Vista, XP, 2000/ME, 98 & NT 40; UNIX, MS-DOS, Novell
Page description languages	Epson FX
Sound pressure level (printing)	52 dB
Mean time between failures (MTBF)	10000 h
Power consumption (typical)	100 W
Operating temperature (T-T)	5 - 40 °C
Operating relative humidity (H-H)	20 - 80 %
