42089201TH Rev.4 30 /
Oki Data CONFIDENTIAL
(2) When not printing
(1) When printing
Paper
Print wire
Platen
Paper
Print wire
Armature assembly
Thermistor
Wire guide
Yoke
Magnet assembly
Spacer
Paper
Figure 2-3
Printhead
