Load The Paper (Standard Configuration)
CAUTION
To avoid damage to the printer caused by printing on the
platen, always position the left tractor unit directly to the left of
the “1” mark on the paper scale.
Figure 23. Using the Paper Scale as a Guide
6. If adjustment is necessary:
a. Unlock the left tractor.
b. Slide the tractor until it is directly to the left of the number
“1” on the paper scale and lock it. You can also use the
paper scale to count columns.
c. Lock the left tractor.
Paper
Paper Scale
Tractor
Tractor Splined Shaft
To Next Page
