Parts Identication: Rear View
USB connector
Parallel connector
Optional Serial/Network connector
Ventilation
Power Connector
Optional Cut Sheet Feeder/Roll Paper Stand
connector
Note: The serial number of your printer is on a label on
the back, beside “S/N.”
1.
2.
3.
4.
5.
6.
Parts Identication: Inside View
Paper Thickness Lever
Ribbon Cartridge
Print Head
Pull-up Guide Assembly
1.
2.
3.
4.
