36
NOTE: If adding a second sensor to an existing module, set the ModBus
address to ↑↑↑↑↓↓↓↓ which represents 11110000 binary (and 240 decimal).
See Chapter 6 | for more information on the ModBus interface. (Note that
DIP switches are pre-set at the factory for all dual-sensor units).
Wiring Conclusion
Once wiring is complete, place the electronics module back in the
housing by pressing the standoff banana jacks into the mating plugs. Be
careful not to pinch any of the wiring. After the module is in place, secure
the windowed top back on the housing and power up the unit.
# # #
