Sensor Type
To enter non-intrusive operation
during the Normal Operating Mode,
place the magnetic wand over the
CH1 designation. The will
display the sensor type for channel
1 for 5 seconds then enter in the
Zero Menu.
NOTE: If you want to operate
channel 2, place the magnetic wand
on CH2 first to enter the setup
menu.
Figure 5-6 Sample Display Entering
Non-Intrusive Mode
Once non-intrusive mode is entered, placing the magnetic wand over CH1,
will allow scrolling through all of the functions that are available. Once the
desired function is reached, a 10-second timer will appear on the bottom
row of the LED display. During this 10-second time out, if the magnetic wand
is placed over CH2, that function is entered. Once a function is entered, a
new timer will appear.
Zeroing
Zeroing is the first option in the
setup menu. A “0 ” is displayed in
the status bit of the display to
designate this function. A 10 second
timer is displayed on the bottom line
of the LED display. To initiate
zeroing, place the magnetic wand
over CH2 during the 10-second
countdown. If you do not initiate
zeroing during the 10-second
countdown, the will return
to the Normal Operating Mode. To
abort zeroing at any time, place the
magnatic wand over CH1.
Figure 5-7 Sample Zeroing Display
If you initiate zeroing, the status bit will start to flash. Once zeroing is
complete, the unit will return to the Normal Operating Mode.
